KEY SPECIFICATIONS
The units batching capabilities include:-
- Each unit is able to batch up to 60 m3 per hour
- High Quality, High Specification mixes for commercial and industrial requirements.
- Able to batch ALL types of spec concrete requirements, including rapid set.
- Multiple batches with different mix requirements
- Shot-Crete
- Dry Mixes
- Completely mobile
- Can address weed and seed issues
ADVANCED TECHNOLOGY
All elements regarding batch accuracy are precision measured several times a second and automatically controlled by a cutting edge PLC system.
- Variable Production Rates: up to 60 cubic meters/hour
- MasterMix Electronic Display: digital counter for calibration and delivery measurement
- Full Function Controls: wireless remote, rear-mounted switch panel
- Hydraulic Control System: advanced, proprietary
- Hydraulic Pump: load sensing, PFC, variable displacement, piston-type tandem
- Proprietary Belted Chain Conveyor System: low cost maintenance
- Dual Cross-Auger Cement Metering
- Variable Cement Metering
- Chemical Admixture System: dual-product, dual-flow
- Power Swing: hydraulic rotary actuator
- Pneumatic Vibrators (optional: Electric or Hydraulic)
- Multiple Powering Options: rear engine PTO, transmission PTO or separate auxiliary engine
- Water Tank: rotationally molded polyethylene
- Fenders: light weight, durable, non-corrosive – poly or stainless steel
OPERATING MADE SIMPLE
Commodity is loaded and segregated in the back unit, once loaded it can travel to the work site and batch concrete on demand with Full Function Controls such as the wireless remote and rear-mounted switch panel the unit can be easily operated with one operator. This one-touch control system can be Pre-loaded with mix designs so you are always ready for any job. Just select the mix design you need and the system automatically adjusts.
